Place of Origin:
Anhui, China
Brand Name:
ABG
Certification:
ISO9001、ISO14001、ISO45001、CQC
The reverse osmosis water filter process uses semi-permeable spiral-wound membranes to remove dissolved solids, organics, pyrogens, submicron colloids, and bacteria from water. Feed water passes through the membranes at a pressure of approximately 16 kg/cm²; water permeates the membrane pores to become purified water, while impurities are concentrated in the reject stream and flushed out. It can remove 90-99% of the total dissolved solids (TDS), 99% of the organics (including pyrogens), and 99% of all bacteria from the feed water.
| N | Name | Specification | Brand | Option |
|---|---|---|---|---|
| 1 | raw water pump | 220V/1 phase/50Hz | ABG | 110V/220V/380V/415V single phase/3 phase 50Hz/60Hz |
| 2 | high pressure pump | CNP | ||
| 3 | quartz sand filter | material: FRP operation: automatic media: quartz sand | China | |
| 4 | activated carbon filter | material: FRP operation: autoamtic media: activated carbon | China | |
| 5 | security filter | U-PVC 20 inch | China | stainless steel 304 |
| 6 | reverse osmosis membrane | membrane housing: SS304 membrane: 2 pcs | China | FRP, Dupont(DOW), Hydranautics, CSM, TORAY |
| 7 | UV sterilizer | stainless steel 304 | China |
| Product Name | Function |
|---|---|
| Raw Water Pump | Provide needed pressure for every pre-treatment filter. |
| Sand Filter | Remove the water contains sediment, manganese, rust, colloid material, and other particles. |
| Activated Carbon Filter | Remove the pigment,smell,organisms, reducing the residual value of water |
| Security Filter | Remove 5 micro particles |
| High Pressure Pump | Provide needed pressure for RO system |
| RO Membrane | Remove particles, colloids, organic impurities, heavy metal ions, bacteria, virus, heat source etc. harmful substances and 97% dissolved salts. |
| UV Sterilizer /Ozone generator | Kill bacterial in water. UV for direct drinking water. Ozone generator for bottle water |
