Place of Origin:
Anhui, China
Brand Name:
ABG
Certification:
ISO9001、ISO14001、ISO45001、CQC
| Water machine -4000Liter per hour | |||
| Inlet flow: | ≥12m3/h | Outlet flow: | 4,000L per hour |
| Inlet pressure: | ≥2KG | Recovery rate: | 60-75% |
| Raw water Conductivity: | ≤300us/cm | Desalination rate: | 98% |
| RO output Conductivity: | ≤10us/cm | Power(380V,50HZ,3P or customized): | 5.5kw |
| Control model: | Automatic | Operating temperature: | 5-45℃ |
Raw water pump---Quartz sand filter---Activated carbon filter---Water softer/Anti-scale dosing system---Security filter---High pressure pump---Reverse osmosis system---UV/Ozone---pure water supply point
| Different water TDS compare and Application | ||||
| Application/Source Water | Bottled water, Sachet Water | Municipal Tap Water | Brackish water | Sea Water |
| TDS Range | 2-10ppm | 100-1000ppm | 2000-20,000ppm | 20,000-40,000ppm |
| Direct Drinking | Yes | Yes/No | No | No |
| Cooking, human consumption, washing | Yes | Yes | No | No |
| Irrigation, industry, animal drinking | Yes | Yes | Yes | No |
| Every part description of the reverse osmosis water filter | |||
| S/N | Commodity name | Description/Application | |
| 1 | Raw water tank | Store water, buffering pressure, overcome instability of supplying water by pipe, ensure to supply water stably and continuously for whole system |
|
| 2 | Raw water pump or called booster pump | Provide needed pressure for every pre-treatment filter | |
| 3 | Mechanical filter or called quartz sand filter or sand filter | We use fiber glass or stainless steel vessel as housing, fill quarts sand, it can filter big particles impurities, suspended substances, colloids etc. |
|
| 4 | Activated carbon filter | We use fiber glass or stainless steel vessel as housing, fill activated carbon, remove color, odor, residual chlorine and organics substances. |
|
| 5 | Water softener, demineralizer, or called Na+ exchanger | Adopt cation resin to soften water, cation resin will absorb Ca2+, Mg2+(main elements for composing scale), reduce hardness of raw water, System can make resin intelligently regenerate, recycling |
|
| 6 | Antiscalant dosing system or PH regulating system | Dosing antiscalant into feed water, prevent the ro membranes from blocking, prolong the lifetime of RO membranes. Regulating PH to suitable range. |
|
| 7 | Security filter or pp filter, or called PP sediment filter | prevent large particles, bacteria, viruses into RO membrane, accuracy is 5µm | |
| 8 | High pressure pump | Provide needed working pressure for RO system, ensure production capacity of pure water. | |
| 9 | RO(reverse osmosis) system | Can remove particles, colloids, organic impurities, heavy metal ions, bacteria, virus, heat source etc. harmful substances and 99% dissolved salts. |
|
