Meta Description: Off-grid solar desalination system producing 10,000 liters of drinking water daily from brackish groundwater. PV + battery storage, containerized, low-maintenance.
Suggested URL: /products/solar-desalination-system-bw10
Clean water is the foundation of every healthy community. The BL-10 delivers 10 m³ (10,000 liters) of safe drinking water per day from brackish boreholes, powered entirely by solar energy with battery storage — enough for villages of 500–1,000 people. Housed in a compact 10-foot container, the unit arrives pre-wired and pre-tested: connect the borehole, mount the PV array, and it starts producing water the same week.
Key Features| Parameter | Value |
|---|---|
| Rated freshwater output | 10 m³/day (10,000 L/day) |
| Feed water TDS (max) | ≤ 6,000 ppm |
| Product water TDS | ≤ 300 ppm |
| Salt rejection | ≥ 98% |
| System recovery | ~60% |
| Specific energy consumption | ~1.5 kWh/m³ |
| PV array (monocrystalline) | 6 kWp |
| Battery (LiFePO₄) | 20 kWh |
| Power supply modes | Solar + battery (off-grid) |
| Operating pressure | 10–25 bar |
| Form factor | 10 ft container |
| Control system | PLC + HMI touchscreen, MPPT |
| Operation temperature | 1–40 °C |
| Design life | ≥ 5 years |
