Place of Origin:
Anhui, China
Brand Name:
ABG
Certification:
ISO9001、ISO14001、ISO45001、CQC
Reverse Osmosis(RO) is a process that uses semi-permeable spiral wound membranes to separate and remove dissolved solids,organic,pyrogens,submicron colloidal matter,color,nitrate and bacteria from water. Feed water is delivered under pressure through the semi-permeable membrane,where water permeates the minute pores of the membrane and is delivered as purified water called permeate water.Impurities in the water are concentrated in the reject stream and flushed to the drain is called concentrate water.
Raw water pump→ mechanical filter(quartz sand filter)→ activated carbon filter→ security filter→ high pressure pump →reverse osmosis system→ Ozone sterilizer (UV sterilizer).
| Applicable water source | Municipal tap water |
| Filtering accuracy | 0.0001micron |
| Water temperature requirements | 5ºC-35ºC |
| Filter hierarchy | RO reverse osmosis |
| RO Membrane | 4040 RO membrane |
| Filter element combination | Quartz sand filtert ank * 1 + Activated carbon filter tank * 1 + Precision filter * 1 + 4040 R0 membrane * 2 |
| Applicable voltage | 220V |
| Hourly Water Output | 0.25 ton, 0.5 ton, 1 ton |
| Inlet Size | 1 inch (inner wire) |
| Outlet Caliber | 1 inch (outer wire) |
| Front life | 3-6 months(depending on local water quality) |
| Ro Membrane Life | 1-2 years (depending on local water quality) |
| Product Features | 1. Intelligent display panel, working status is clear at a glance. 2. Stainless steel body, more durable. 3. Effective descaling of bacteria, viruses, heavy metals, etc. |
The application scope of single-stage reverse osmosis equipment:drinking purified water,pure
water for beverage and food factory production,daily chemical production water,biopharmaceutical
water,medical device cleaning water,reagent preparation water,hospital dialysis water,oral liquid water, medical purified water,and electronic semiconductor production water
