Pure Solar-powered Drinking Machine - Coin-operated Drinking Machine

Place of Origin:

Anhui, China

Brand Name:

ABG

Certification:

ISO9001、ISO14001、ISO45001、CQC

Request A Quote

Pure Solar-powered Drinking Machine - Coin-operated Drinking Machine

Product Details

Processing Capacity:

99%

Productivity:

10000L/Hour

Weight (kg):

800

Function:

Make Pure Drinking Water

Voltage:

220v 380V 50HZ 60HZ（Or Customize）

Advantage:

24 Hours Automatic Running

Core Components:

Pressure Vessel, Pump, Engine, Motor, PLC

Application:

Water Purification

Payment & Shipping Terms

Minimum Order Quantity

Price

USD2000-4000

Packaging Details

Wooden /Box

Delivery Time

7-15 Days

Payment Terms

L/C,T/T,Western Union

Supply Ability

100sets/month

Pure Solar Energy Community Park School Stainless Steel Drinking Water Dispenser Scenic Area Direct Drinking Water

Get Best Price

Self Service Solar Powered Water Dispenser Coin Operated With RO Reverse Osmosis

Get Best Price

Industrial Solar Powered Drinking Water System Stainless Steel Drinking Water Treatment Equipment

Get Best Price

86-0551-62826800-(Work Time)

Contact Now

Product Description

Introduction:

Solar-powered drinking water treatment equipment is a device that uses solar energy as its power source to treat drinking water. Common ones include solar distillers, solar photocatalytic oxidation equipment, and solar-driven membrane separation equipment, etc. For example, solar distillers desalinate seawater or other impure water by using solar energy to heat and evaporate water, and then cooling and condensing the water vapor into fresh water. Solar photocatalytic oxidation equipment utilizes solar energy to stimulate photocatalysts, generating highly oxidizing substances that decompose organic pollutants in water and kill bacteria. Solar-driven membrane separation equipment uses solar panels to power the membrane separation process, achieving the filtration and purification of water.

Working principle
The solar-powered community direct drinking water equipment mainly converts tap water into directly drinkable water through the following steps:

Pretreatment ‌ : Firstly, the water passes through a multi-stage filtration system and disinfection technology to remove suspended solids, large particle impurities, odors and organic compounds, etc. Youdaoplaceholder2
Reverse osmosis membrane filtration ‌ : Under the high pressure of reverse osmosis membranes, water removes harmful substances such as bacteria, viruses, heavy metals and pesticide residues ‌.
Ultraviolet disinfection ‌ : Further kill bacteria and viruses in water through ultraviolet lamps or ozone lamps to ensure water hygiene ‌

Pure solar integrated machine 25-S01.3 series
CBO Size	Model	Performance	Core Components	Maintenance Cost
Micro (less than 500 people) - 1-2 tons per day	BL-CT/J08B	1. It can be powered solely by solar energy. 2. An integrated outdoor water purification station, without any need for any equipment rooms. 3. The product is equipped with online water quality monitoring for both inlet and outlet water, allowing for local or intelligent remote storage (optional). This ensures that every drop of water is healthy and safe, and there are records and evidence to verify. 4. Card payment, one-touch water supply, remote recharge, achieving lower operation and management costs (multiple modes can be customized for production).	Pre-filtration lasts for about 3 to 6 months, while the core membrane lasts for more than half a year. The duration is determined based on the quality of the incoming water.	The total cost of all equipment consumables for the year does not exceed 2,000 RMB.
Small (500 - 1500 people) 3 - 4 tons per day	BL-CT/J16B
Medium-sized (1,500 - 3,000 people) 4 - 5 tons per day	BL-CT/J40B		The pre-filtration lasts for about half a year, while the core membrane lasts for more than one year. The duration depends on the quality of the incoming water.	Over a period of about two years, the total cost of equipment and consumables does not exceed 3,000 yuan.
